| Model |
Effective volume m3 |
Processing ability m3 |
Diameter of impellermm | Impeller speedr/min |
Blower wind pressure Kpa |
Maximum inflation m3/m2.min |
Motor power for mixing kw | Scraper motor power kw |
Single tank weight kg |
| KYF-1 | 1 | 0.2-1 | 340 | 281 | ≥12.6 | 2 | 4 | 1.1 | 826 |
| KYF-2 | 2 | 0.4-2 | 410 | 247 | ≥14.7 | 2 | 5.5 | 1.1 | 1419 |
| KYF-3 | 3 | 0.6-3 | 480 | 219 | ≥19.8 | 2 | 7.5 | 1.5 | 1885 |
| KYF-4 | 4 | 1.2-4 | 550 | 200 | ≥19.8 | 2 | 11 | 1.5 | 2206 |
| KYF-8 | 8 | 3.0-8 | 630 | 175 | ≥21.6 | 2 | 15 | 1.5 | 4190 |
| KYF-16 | 16 | 4.0-16 | 740 | 160 | ≥25.5 | 2 | 30 | 1.5 | 6019 |
| KYF-24 | 24 | 4.0-24 | 800 | 150 | ≥30.4 | 2 | 30 | 1.5 | 7500 |
| KYF-38 | 38 | 10-38 | 880 | 138 | ≥34.3 | 2 | 37 | 1.5 | 10300 |
